Forum Index : Microcontroller and PC projects : MM+: Load pictures fast
| Author | Message | ||||
| matherp Guru  Joined: 11/12/2012 Location: United KingdomPosts: 10570 |
The in-built MM+ firmware takes 14 seconds to display the attached 800x480 image of a tiger saved as a .BMP on a SSD1963 display.
The attached code takes just 2 seconds to display the same image, saved as a binary portable pixelmap (.PPM), at the same resolution and same colour depth. Any semi-decent photo software will be able to save images as .BMP and .PPM. Make sure to choose the binary option for the .PPM files. This code uses the MX170 loadable SDcard driver configured for the Micromite+. The loadable SDcard driver uses the PetitFAT software which is much lighter weight than the Microchip SD stack. Also the .PPM image files are easier to interpret than .BMP. The code posted is configured and tested on a 100-pin Micromite with a SSD1963 display configured as usual with OPTION LCDPANEL. To use on a 64-pin version substitute the pair of CFunctions that are commented out in the code. The code has been tested on 4.3", 5", and 7" SSD1963 displays. The use of the loadable SDcard driver is compatible with normal use of the in-built SDcard routines in the MM+ so you can still use "FILES" etc. and just use the driver for faster load of images. Alternatively you can use the loadable driver functionality as explained in this post The code includes slideshow functionality for all .PPM files found on the SDcard. To display a single image just use the command DisplayPicture "image.ppm",0,0
The two zeros are the x,y coordinates of the top left of the picture. i.e. the syntax is the same as "LOAD IMAGE" Of course the CFunctions and the Displaypicture routine can be stored in the LIBRARY to reduce their footprint. Option explicit
option default NONE ' ' Demo of functionality of PetitFAT for Micromite MX470 with SSD1963 driver ' const SD_CS_PIN = 47 'Connection to CS on SD card ' connect other SD card pins as per manual i.e. SPI 2 const pausetime = 3 'pause between pics in seconds ' ' Codes for use of the SD card driver ' see http://www.thebackshed.com/forum/forum_posts.asp?TID=8648 for more details ' const mount=0 const fileopen=1 const readfile=2 const writefile=3 const opendir=4 const readdir=5 ' dim pics$(200) length 18, s$ length 18 dim integer i,num=0 cls ' sdcard mount,SD_CS_PIN,0 'set up the chip select pin for the SDcard and SPI speed to maximum ' reduce speed if too fast for your card ' "speed" controls how fast the SPI bus operates. If omitted the bus runs at 7.5MHz which should suit most SDHC cards. ' Assuming the CPU is running at 100MHz, a parameter of 0 runs the bus at 25MHz which works for me on Class-10 cards. ' Values in the range 0-fastest to 10-slowest should cater for any speed of card. The default if omitted is 2. ' open directory SDcard opendir,"" 'read the directory and store the filenames of all .PPM files found do s$="" SDcard readdir,s$ if right$(s$,4)=".PPM" then pics$(num)=s$ num=num+1 endif loop while s$<>"" do DisplayPicture pics$(i),0,0 pause pausetime*1000 i=i+1 i=i mod num loop END '*************************************************************************************************** ' ' Display a picture from the SD card on SSD1963 ' Picture must be in binary .PPM format ' ' Parameters are: ' PIC$ = filename of the picture to be displayed ' StartX% = X coordinate of the top left of the picture ' StartY% = Y coordinate of the top left of the picture ' ' Note: the routine checks that the picture is not too big for the screen and reports an error if it is ' Sub DisplayPicture(PIC$, StartX%, StartY%) LOCAL Buffer$,addbuffer$ length 3 LOCAL Result%=-1 LOCAL NumBytes%,a%,i% local integer buff(511) SDcard fileopen,PIC$ 'Read the first 128 bytes Buffer$=STRING$(128," ") SDcard readfile,buffer$,0,len(buffer$),NumBytes% a%=instr(buffer$,chr$(10)) ' look for the first CR if left$(buffer$,a%-1)="P6" then buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the second CR buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(32)) ' look for the space between dimensions local width%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the third CR LOCAL height%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the fourth CR buffer$=right$(buffer$,len(buffer$)-a%) a%=len(buffer$) mod 3 addBuffer$=STRING$(3-a%," ") ' we need to make sure we have a number of bytes divisible by three in the buffer SDcard readfile,addbuffer$,-1,len(addbuffer$),NumBytes% buffer$=buffer$+addbuffer$ if (StartX%+width%>MM.HRES) OR (StartY%+height%>MM.VRES) then print pic$," too big", width%," x",height% else defineregionSSD StartX%, StartY%, width%, height% DisplayBufferSSD Buffer$ do SDcard readfile,buff(),-1,4095,NumBytes% if numbytes%<>0 then DisplayBufferSSD Buff(),numbytes% loop while NumBytes%<>0 endif else Print "Invalid File Format" endif end sub ' 'CSub DisplayBufferSSD '64-pin ' 00000000 ' 14A00003 90880000 10000004 24050001 8CA80000 00002821 2508FFFF 00A8102A ' 10400017 00852021 3C02BF88 24030800 90870000 24A50003 00A8302A 34E71800 ' AC476430 AC436134 AC436138 90870001 34E71800 AC476430 AC436134 AC436138 ' 90870002 24840003 34E71800 AC476430 AC436134 AC436138 54C0FFEE 90870000 ' 03E00008 00000000 'End CSub ' 'CSub defineregionSSD '64-pin ' 00000000 ' 3C029D00 8C420090 8C830000 8CA50000 8CC40000 24081000 8CE60000 3C07BF88 ' ACE86134 80420015 24A7FFFF 2468FFFF 00E63021 24070001 10470004 01042021 ' 24070003 14470005 3C029D00 00C03821 00604021 10000007 00803021 8C420094 ' 00A04021 8C470000 24E7FFFF 00E42823 00E33823 00086202 00065A02 3C02BF88 ' 24030800 24041000 00055202 34C61800 358C1800 35081800 356B1800 240D022A ' AC4D6430 00074A02 AC436134 34A51800 AC436138 354A1800 AC446138 AC4C6430 ' AC436134 AC436138 AC486430 AC436134 AC436138 AC4B6430 AC436134 AC436138 ' AC466430 2406022B AC436134 35291800 AC436138 34E71800 AC446134 AC466430 ' AC436134 AC436138 AC446138 AC4A6430 AC436134 AC436138 AC456430 2405022C ' AC436134 AC436138 AC496430 AC436134 AC436138 AC476430 AC436134 AC436138 ' AC446134 AC456430 AC436134 AC436138 AC446138 03E00008 00000000 'End CSub ' CSub DisplayBufferSSD '100-pin 00000000 14A00003 90880000 10000004 24050001 8CA80000 00002821 2508FFFF 00A8102A 10400017 00852021 3C02BF88 24030200 90870000 24A50003 00A8302A 34E70300 AC476430 AC436434 AC436438 90870001 34E70300 AC476430 AC436434 AC436438 90870002 24840003 34E70300 AC476430 AC436434 AC436438 54C0FFEE 90870000 03E00008 00000000 End CSub ' CSub defineregionSSD '100-pin 00000000 3C029D00 8C420090 8C830000 8CA50000 8CC40000 24080100 8CE60000 3C07BF88 ACE86434 80420015 24A7FFFF 2468FFFF 00E63021 24070001 10470004 01042021 24070003 14470005 3C029D00 00C03821 00604021 10000007 00803021 8C420094 00A04021 8C470000 24E7FFFF 00E42823 00E33823 00086202 00065A02 3C02BF88 24030200 24040100 00055202 34C60300 358C0300 35080300 356B0300 240D022A AC4D6430 00074A02 AC436434 34A50300 AC436438 354A0300 AC446438 AC4C6430 AC436434 AC436438 AC486430 AC436434 AC436438 AC4B6430 AC436434 AC436438 AC466430 2406022B AC436434 35290300 AC436438 34E70300 AC446434 AC466430 AC436434 AC436438 AC446438 AC4A6430 AC436434 AC436438 AC456430 2405022C AC436434 AC436438 AC496430 AC436434 AC436438 AC476430 AC436434 AC436438 AC446434 AC456430 AC436434 AC436438 AC446438 03E00008 00000000 End CSub ' CSub sdcard '64-pin or 100-pin 00000676 'rcv_spi 240300FF 3C02BF80 AC435A20 3C03BF80 8C625A10 30420080 1040FFFD 3C02BF80 8C425A20 03E00008 304200FF 'xmit_spi 308400FF 3C02BF80 AC445A20 3C03BF80 8C625A10 30420080 1040FFFD 3C02BF80 8C425A20 03E00008 304200FF 'mem_set 10C00006 00801021 00862021 A0450000 24420001 5444FFFE A0450000 03E00008 00000000 'mem_cmp 2407FFFF 24C6FFFF 10C70008 00001021 80830000 80A20000 00621023 14400003 24840001 1000FFF7 24A50001 03E00008 00000000 'mystrlen 80830000 10600006 00001021 24420001 00821821 80630000 5460FFFD 24420001 03E00008 00000000 'send_cmd 27BDFFE0 AFBF001C AFB20018 AFB10014 AFB00010 309100FF 7C111420 04410009 00A09021 24040077 00002821 0411FFF4 00000000 2C430002 10600034 8FBF001C 3231007F 3C109D00 8E030090 8E02001C 80640030 0040F809 24050006 0411FFB2 00000000 8E030090 8E02001C 80640030 0040F809 24050005 0411FFAB 00000000 02202021 0411FFB3 00000000 00122602 0411FFB0 00000000 7E443C00 0411FFAD 00000000 7E443A00 0411FFAA 00000000 324400FF 0411FFA7 00000000 24020040 12220006 24040095 3A310048 24020001 24030087 00402021 0071200A 0411FF9D 00000000 2410000A 0411FF8F 00000000 7C021C20 04610004 2610FFFF 321000FF 1600FFF9 00000000 8FBF001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0020 'disk_readp 27BDFFD8 AFBF0024 AFB40020 AFB3001C AFB20018 AFB10014 AFB00010 00809021 00C09821 00E0A021 3C029D00 8C42008C 8C4300FC 30630008 00051240 24040051 0043280A 0411FFA6 00000000 14400024 24100001 34109C40 241100FF 0411FF6A 00000000 14510005 2610FFFF 1600FFFB 00000000 1000001A 24100001 240300FE 14430017 24100001 00138823 26310202 12600006 02348823 0411FF5B 00000000 2673FFFF 1660FFFC 00000000 02548021 0411FF55 00000000 A2420000 26520001 1650FFFB 00000000 0411FF4F 00000000 2631FFFF 1620FFFC 00000000 00008021 3C029D00 8C430090 8C42001C 80640030 0040F809 24050006 0411FF43 00000000 02001021 8FBF0024 8FB40020 8FB3001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0028 'clust2sect 24A5FFFE 8C830008 2463FFFE 00A3182B 10600005 00001021 90830002 8C820014 70A32002 00821021 03E00008 00000000 'dir_rewind 27BDFFE8 AFBF0014 AFB00010 00A08021 A4A00000 8CA50008 24030001 10A30015 24020001 8C830008 00A3182B 50600012 8FBF0014 54A00008 AE05000C 90830000 24020003 54620008 AE00000C 8C850010 10A00005 AE05000C 0411FFDD 00000000 10000003 AE020010 8C820010 AE020010 00001021 8FBF0014 8FB00010 03E00008 27BD0018 'create_name 27BDFFE0 AFBF001C AFB10018 AFB00014 00A08021 8C910004 02202021 24050020 2406000B 0411FF18 00000000 8E080000 00002021 00001821 24070008 2409002F 2406002E 240A0008 01031021 90420000 24630001 2C450021 14A00018 306300FF 50490017 01031821 10460003 0087282B 14A00008 2445FF9F 54EA0011 01031821 5446000F 01031821 01402021 1000FFEE 2407000B 30A500FF 2CA5001A 10A00003 02242821 2442FFE0 304200FF A0A20000 24840001 1000FFE4 308400FF 01031821 AE030000 2C420021 A222000B 00001021 8FBF001C 8FB10018 8FB00014 03E00008 27BD0020 'get_clust 90840000 24020003 14820006 00001821 90A30015 00031A00 90A20014 00621825 00031C00 90A2001B 00021200 90A4001A 00441025 03E00008 00621025 'get_fat 27BDFFE0 AFBF001C 2CA20002 1440001B 24030001 8C820008 00A2102B 10400018 00601021 000519C2 8C82000C 30A6007F 27A40010 00622821 00063080 24070004 0411FF31 00000000 1440000C 24030001 93A30013 00031E00 93A20012 00021400 00621825 93A20010 00621825 93A20011 00021200 00621825 7C63D800 00601021 8FBF001C 03E00008 27BD0020 'dir_next 27BDFFE0 AFBF001C AFB20018 AFB10014 AFB00010 00808821 00A08021 94B20000 26520001 3252FFFF 12400028 24020003 8CA30010 50600026 8FBF001C 3242000F 54400021 A6120000 24630001 ACA30010 8CA5000C 14A00007 00121902 94830004 0243182B 14600017 24020003 10000018 8FBF001C 90820002 2442FFFF 00621024 54400011 A6120000 0411FFBA 00000000 00402821 2C430002 1460000C 24020001 8E230008 00A3182B 10600008 24020003 AE05000C 02202021 0411FF39 00000000 AE020010 A6120000 00001021 8FBF001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0020 'dir_find 27BDFFD8 AFBF0024 AFB30020 AFB2001C AFB10018 AFB00014 00809821 00A08821 00C09021 0411FF31 00000000 14400021 00408021 96260000 30C6000F 02402021 8E250010 00063140 24070020 0411FED2 00000000 0002802B 16000017 02001021 92420000 50400013 24100003 9242000B 30420008 14400008 02602021 02402021 8E250004 2406000B 0411FE64 00000000 10400008 02602021 02202821 0411FF9F 00000000 1040FFE3 00408021 10000002 02001021 02001021 8FBF0024 8FB30020 8FB2001C 8FB10018 8FB00014 03E00008 27BD0028 'follow_path 27BDFFE0 AFBF001C AFB20018 AFB10014 AFB00010 00809021 00A08021 AFA7002C 80E20000 24030020 14430006 00C08821 24E70001 AFA7002C 80E20000 5043FFFD 24E70001 2403002F 54430004 AE000008 24E70001 AFA7002C AE000008 8FA2002C 90420000 2C420020 10400008 02002021 02402021 02002821 0411FEE7 00000000 1000001B A2200000 02002021 27A5002C 0411FF02 00000000 14400015 02402021 02002821 02203021 0411FFA0 00000000 14400010 8FBF001C 8E030004 9063000B 5460000D 8FB20018 9222000B 30420010 10400006 02402021 02202821 0411FF28 00000000 1000FFE8 AE020008 24020003 8FBF001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0020 'pf_lseek 27BDFFD8 AFBF0024 AFB30020 AFB2001C AFB10018 AFB00014 00808021 1080004F 24020005 90830001 30630001 1060004B 24020004 8C82001C 0045902B 00B2100A 00409021 8C830018 AC800018 12400043 00001021 90910002 10600012 00118A40 2463FFFF 2642FFFF 0051001B 022001F4 00001012 0071001B 022001F4 00002012 0044102B 54400008 8E050020 00111023 00431824 AE030018 02439023 10000003 8E050024 8E050020 AE050024 0232102B 10400018 00119823 02519023 02002021 0411FEFC 00000000 00402821 2C420002 54400006 A2000001 8E020008 00A2102B 54400004 AE050024 A2000001 1000001B 24020001 8E020018 00511021 AE020018 02531021 00511821 0223182B 5460FFEB 00409021 8E020018 00529021 AE120018 02002021 0411FE6E 00000000 54400004 92040002 A2000001 10000008 24020001 2484FFFF 8E030018 00031A42 00831824 00431021 AE020028 00001021 8FBF0024 8FB30020 8FB2001C 8FB10018 8FB00014 03E00008 27BD0028 'pf_read 27BDFFD0 AFBF002C AFB60028 AFB50024 AFB40020 AFB3001C AFB20018 AFB10014 AFB00010 00808021 00A0A821 00E09821 ACE00000 1080004A 24020005 90830001 30630001 10600046 24020004 8C92001C 8C820018 02429023 0246102B 00C2900A 1240003F 00001021 00A0A021 24160200 8E020018 304301FF 5460001F 8E060018 00021A42 92110002 2631FFFF 00718824 323100FF 1620000E 02002021 54400003 8E050024 10000003 8E020020 0411FEA3 00000000 2C430002 50600004 AE020024 A2000001 10000026 24020001 02002021 8E050024 0411FE24 00000000 14400004 00518821 A2000001 1000001D 24020001 AE110028 8E060018 30C601FF 02C61023 0052882B 0251100A 00408821 00002021 0295200B 8E050028 00403821 0411FDC9 00000000 50400004 8E020018 A2000001 1000000B 24020001 00511021 AE020018 02519023 8E620000 00511021 12400003 AE620000 1000FFC6 0291A021 00001021 8FBF002C 8FB60028 8FB50024 8FB40020 8FB3001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0030 'disk_initialize 27BDFFD0 AFBF002C AFB30028 AFB20024 AFB10020 AFB0001C 2403003B 3C02BF80 AC435A30 3C029D00 8C430090 8C42001C 80640030 0040F809 24050006 2410000A 0411FD20 00000000 2610FFFF 321000FF 1600FFFB 24040040 00002821 0411FD4F 00000000 24030001 14430061 3C029D00 24040048 240501AA 0411FD48 00000000 24030001 14430037 240400E9 27B00010 27B10014 0411FD0B 00000000 A2020000 26100001 1611FFFB 93A30012 24020001 1462004E 00008021 93A30013 240200AA 1462004B 3C029D00 10000008 24112710 0040F809 24040064 2631FFFF 16200005 240400E9 1000003F 00008021 3C109D00 240400E9 3C054000 0411FD28 00000000 5440FFF3 8E020004 12200038 00008021 2404007A 00002821 0411FD20 00000000 14400033 3C029D00 24110004 0411FCE5 00000000 27A40010 00901821 26100001 1611FFFA A0620000 93B00010 32100040 2402000C 24030004 0070100A 10000023 00408021 00002821 0411FD0C 00000000 2C420002 24030002 24100001 0062800B 240300E9 24130041 0062980B 24112710 10000006 3C129D00 0040F809 24040064 2631FFFF 52200011 00008021 02602021 00002821 0411FCF9 00000000 5440FFF6 8E420004 52200009 00008021 24040050 24050200 0411FCF1 00000000 10000003 0002800B 10000002 3C029D00 3C029D00 8C43008C AC7000FC 8C430090 8C42001C 80640030 0040F809 24050006 0411FCAD 00000000 12000005 3C029D00 8C420090 8043003C 3C02BF80 AC435A30 2E020001 8FBF002C 8FB30028 8FB20024 8FB10020 8FB0001C 03E00008 27BD0030 'disk_writep 27BDFFE0 AFBF001C AFB20018 AFB10014 AFB00010 10800014 00808021 30A5FFFF 10A00052 00009021 97828010 1040004F 00858821 92040000 26100001 0411FC99 00000000 97828010 2442FFFF 3042FFFF 12110045 A7828010 5440FFF7 92040000 10000042 00009021 10A00016 97908010 3C029D00 8C42008C 8C4300FC 30630008 00051240 24040058 0043280A 0411FCB0 00000000 14400035 24120001 240400FF 0411FC80 00000000 240400FE 0411FC7D 00000000 24020200 A7828010 1000002B 00009021 26100002 12000008 2610FFFF 2411FFFF 00002021 0411FC72 00000000 2610FFFF 1611FFFC 00002021 0411FC62 00000000 3042001F 24030005 14430010 24120001 10000005 241207D0 0040F809 240403E8 10000003 2652FFFF 241100FF 3C109D00 0411FC54 00000000 50510004 2E520001 5640FFF5 8E020004 24120001 3C029D00 8C430090 8C42001C 80640030 0040F809 24050006 0411FC47 00000000 10000003 02401021 00009021 02401021 8FBF001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0020 'pf_write 27BDFFD0 AFBF002C AFB60028 AFB50024 AFB40020 AFB3001C AFB20018 AFB10014 AFB00010 00808021 00C09021 00E09821 ACE00000 1080007B 24020005 90830001 30640001 10800077 24020004 14C00010 30630040 5060000A 92020001 00002021 00002821 0411FF84 00000000 50400004 92020001 A2000001 1000006A 24020001 304200BF A2020001 10000066 00001021 54600006 8E03001C 8E030018 2402FE00 00621024 AE020018 8E03001C 8E020018 00621023 0052182B 14600005 00000000 00A0A021 24150200 10000005 2416FFBF 1440FFFB 00409021 10000053 8FBF002C 8E020018 304301FF 54600029 8E110018 00021A42 92110002 2631FFFF 00718824 323100FF 1620000E 02002021 54400003 8E050024 10000003 8E020020 0411FD30 00000000 2C430002 50600004 AE020024 A2000001 1000003B 24020001 02002021 8E050024 0411FCB1 00000000 14400004 00512821 A2000001 10000032 24020001 AE050028 00002021 0411FF43 00000000 50400004 92020001 A2000001 10000029 24020001 34420040 A2020001 8E110018 323101FF 02B18823 0232102B 0242880A 02802021 02202821 0411FF33 00000000 50400004 8E020018 A2000001 10000019 24020001 00511021 AE020018 8E620000 00511021 AE620000 8E020018 304201FF 5440000D 02519023 00002021 00002821 0411FF21 00000000 50400004 92020001 A2000001 10000007 24020001 00561024 A2020001 02519023 1640FFB1 0291A021 00001021 8FBF002C 8FB60028 8FB50024 8FB40020 8FB3001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0030 'check_fs 27BDFFE0 AFBF001C AFB10018 AFB00014 00808021 00A08821 240601FE 24070002 0411FC1E 00000000 14400028 24030003 92040001 00042200 92020000 00822025 7C042620 2402AA55 14820020 24030002 02002021 02202821 24060036 24070002 0411FC0E 00000000 1440000A 02002021 92040001 00042200 92020000 00822025 7C042620 24024146 10820010 00001821 02002021 02202821 24060052 24070002 0411FBFE 00000000 14400008 24030001 92030001 00031A00 92020000 00621825 7C031E20 38634146 0003182B 00601021 8FBF001C 8FB10018 8FB00014 03E00008 27BD0020 'pf_mount 27BDFFB8 AFBF0044 AFB10040 AFB0003C 00808021 0411FE39 00000000 30420001 14400087 24030002 27A40010 00002821 0411FFBA 00000000 24030001 1443001A 00008821 27A40010 00002821 240601BE 24070010 0411FBD8 00000000 14400078 24030001 93A20014 10400075 24030006 93B1001B 00118E00 93A2001A 00021400 02228825 93A20018 02228825 93A20019 00021200 02228825 27A40010 02202821 0411FF9E 00000000 24040003 10440064 24030001 14400062 24030006 27A40010 02202821 2406000D 24070024 0411FBBA 00000000 1440005A 24030001 93A2001A 00021200 93A30019 00431025 1440000C 93A30013 93A3002A 00031E00 93A20029 00021400 00621025 93A30027 00431025 93A30028 00031A00 00431025 93A30013 70431002 93A60012 00063200 93A30011 00C33025 02268821 AE11000C 93A50010 A2050002 93A40015 00042200 93A30014 00832025 A6040004 93A30017 00031A00 93A70016 00671825 1460000B 00042102 93A70026 00073E00 93A30025 00031C00 00E31825 93A70023 00671825 93A70024 00073A00 00671825 00661823 00621823 00641823 0065001B 00A001F4 00003012 24C50002 AE050008 24C6F00A 3407EFFF 00C7302B 2CA70FF7 24030002 0066380B 3403FFF7 00A3282B 10A0001F 24030003 10E00017 24030006 24030003 14E3000D A2070000 93A50032 00052E00 93A30031 00031C00 00A32825 93A3002F 00A32825 93A30030 00031A00 00A31825 10000003 AE030010 00511821 AE030010 02248821 02221021 AE020014 A2000001 00001821 00601021 8FBF0044 8FB10040 8FB0003C 03E00008 27BD0048 1000FFE6 A2030000 'pf_open 27BDFFA0 AFBF005C AFB10058 AFB00054 00808821 00A03821 10800025 24100005 A0800001 27A20024 AFA20014 27A50010 27A60030 0411FC97 00000000 1440001C 00408021 93A20030 10400018 93A2003B 30420010 54400016 24100003 02202021 27A50030 0411FBEB 00000000 AE220020 93A3004F 00031E00 93A2004E 00021400 00621025 93A3004C 00431025 93A3004D 00031A00 00431025 AE22001C AE200018 24020001 10000002 A2220001 24100003 02001021 8FBF005C 8FB10058 8FB00054 03E00008 27BD0060 'pf_opendir 27BDFFB0 AFBF004C AFB10048 AFB00044 00808021 00A08821 00C03821 10800018 24020005 27A20010 ACA20004 27A6001C 0411FC66 00000000 14400012 8FBF004C 93A2001C 1040000B 02002021 93A30027 30630010 1060000A 24020003 02002021 27A5001C 0411FBB9 00000000 AE220008 02002021 02202821 0411FB5A 00000000 8FBF004C 8FB10048 8FB00044 03E00008 27BD0050 'get_fileinfo 8C830010 10600036 24C20009 90A30000 24040020 1064000E 00A02021 244A0008 24090005 240800E5 10000003 240B0020 106B0007 24840001 00693826 0107180A A0430000 24420001 544AFFF9 90830001 90A40008 24030020 1083000A 2403002E A0430000 90A30008 24040020 1464001E 24420001 10000004 90A3000B A0430000 24420001 90A3000B A0C30008 90A4001F 00042600 90A3001E 00031C00 00831825 90A4001C 00641825 90A4001D 00042200 00641825 ACC30000 90A30019 00031A00 90A40018 00641825 A4C30004 90A30017 00031A00 90A40016 00641825 A4C30006 03E00008 A0400000 A0430000 90A30009 24040020 1064FFE3 24420001 A0430000 90A3000A 1464FFDD 24420001 1000FFDE 90A3000B 'dir_read 27BDFFD8 AFBF0024 AFB40020 AFB3001C AFB20018 AFB10014 AFB00010 00809821 00A08021 00C08821 24020003 241200E5 10000019 2414002E 30C6000F 02202021 00063140 24070020 0411FAA7 00000000 0002102B 54400016 AE000010 92230000 50600012 24020003 10720005 9224000B 10740003 30840008 1080000E 8FBF0024 02602021 02002821 0411FB78 00000000 54400007 AE000010 8E050010 54A0FFE6 96060000 10400003 8FBF0024 AE000010 8FBF0024 8FB40020 8FB3001C 8FB20018 8FB10014 8FB00010 03E00008 27BD0028 'pf_readdir 27BDFFB0 AFBF004C AFB20048 AFB10044 AFB00040 00808821 00A08021 00C09021 1080001B 24020005 27A20010 14C00005 ACA20004 0411FACD 00000000 10000015 8FBF004C 27A6001C 0411FFB9 00000000 24030003 10430004 02002021 1440000D 8FBF004C 02002021 27A5001C 02403021 0411FF6A 00000000 02202021 02002821 0411FB46 00000000 38430003 0003100A 8FBF004C 8FB20048 8FB10044 8FB00040 03E00008 27BD0050 'getFPC 27BDFFF8 AFBF0004 00852023 03E42021 ACC40000 8FBF0004 03E00008 27BD0008 'errstring 27BDFFE0 AFBF001C AFB00018 00808021 00002021 3C059D00 24A518D0 27A60010 0411FFEF 00000000 8FA20010 1200003C 24030001 16030006 24030002 8FA30010 3C049D00 24842468 10000012 00832021 56030006 3C049D00 8FA30010 3C049D00 24842478 10000013 00832021 24842458 00822021 24020003 16020007 24020004 8FA30010 3C049D00 24842484 10000011 00832021 24020004 16020007 24020005 8FA30010 3C049D00 24842490 10000011 00832021 24020005 16020007 24020006 8FA30010 3C049D00 248424A0 10000010 00832021 24020006 16020007 24020007 8FA30010 3C049D00 248424B0 10000008 00832021 24020007 16020006 3C029D00 8FA30010 3C049D00 248424C4 00832021 3C029D00 8C4200BC 0040F809 00000000 8FBF001C 8FB00018 03E00008 27BD0020 'main 27BDFFA8 AFBF0054 AFBE0050 AFB7004C AFB60048 AFB50044 AFB40040 AFB3003C AFB20038 AFB10034 AFB00030 00808021 00A08821 00C0A821 00E09821 3C02BF80 34038260 AC435A00 24030C00 AC435A40 3C039D00 8C640090 8084003C AC445A30 8C72008C 26540050 8E060000 24020001 10C20006 26570078 24020006 10C20003 24020007 14C20006 24020004 82250000 04A10007 00001021 1000000F 03A52821 14C2001A 24020007 1000FFF9 82250000 27A40010 00821821 02222021 90840000 A0640000 24420001 00A2182A 1060FFF9 27A40010 03A52821 24020006 14C20005 A0A00011 3C029D00 8C4200C4 0040F809 00000000 8E060000 24020001 10C20007 24020006 10C20005 24020007 10C20003 24020004 54C200A6 8E030000 3C029D00 8C430090 80640030 8C430088 00041080 00431021 8C430000 24020065 10620003 24040007 0411FF62 00000000 3C02BF81 8C43F220 7C63D800 3C020580 3442B053 00621026 24030030 24040014 0082180B 00601021 3C039D00 8C630088 00431021 8C430000 24020065 10620054 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000C 24040005 0065200A 24050008 0040F809 00003021 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000C 24040005 0065200A 24050064 0040F809 00003021 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000B 2404002F 0065200A 24050002 0040F809 00003021 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000B 2404002F 0065200A 24050064 0040F809 00003021 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000A 24040004 0065200A 24050008 0040F809 00003021 3C029D00 8C420010 3C03BF81 8C65F220 7CA5D800 3C030580 3463B053 00A32826 2403000A 24040004 0065200A 24050064 0040F809 00003021 3C02BF81 8C43F220 7C63D800 3C020580 3442B053 1462000C 3C02BF81 8C43FA90 24040001 7C831804 AC43FA90 3C02BF81 8C43FCA0 24040006 7C831804 AC43FCA0 1000000B 3C02BF80 8C43FA90 24040007 7C831804 AC43FA90 3C02BF81 8C43FC9C 24040006 7C831804 AC43FC9C 3C02BF80 34038260 AC435A00 24030C00 AC435A40 3C029D00 8C42008C AC4000F8 02802021 0411FD3E 00000000 00402021 0411FED5 00000000 8E030000 24020001 1462000A 24020002 02802021 27A50011 0411FDCB 00000000 00402021 0411FECA 00000000 8E030000 24020002 54620022 8E030000 8EA50000 04A00006 02802021 0411FAA6 00000000 00402021 0411FEBE 00000000 8E660000 28C20100 1040000B 02802021 26250001 27A70020 0411FAF9 00000000 00402021 0411FEB3 00000000 8FA20020 10000008 A2220000 02202821 27A70020 0411FAEF 00000000 00402021 0411FEA9 00000000 8FA30020 8FA20068 AC430000 8E030000 24020003 5462007B 8E030000 8EA20000 04410005 3C029D00 8C42008C 8C4200F8 AEA20000 3C029D00 8C42008C 8C4400F8 8E630000 00831821 AC4300F8 8EB60000 241EFE00 02DEF024 02802021 03C02821 0411FA74 00000000 00402021 0411FE8C 00000000 8E660000 28C20100 02221021 AFA2002C 8EA20000 105E004C 32D601FF AFB60028 3C029D00 8C420040 0040F809 24040200 0040B021 02802021 00402821 24060200 27A70020 0411FABC 00000000 00402021 0411FE76 00000000 02802021 03C02821 0411FA57 00000000 00402021 0411FE6F 00000000 8E650000 8FA20028 00452821 2CA20201 14400003 0000F021 24BEFE00 24050200 8FA30028 0065102A 10400009 8FA3002C 8FA40028 02C41021 02C52821 90640000 A0440000 24420001 1445FFFC 24630001 02802021 02C02821 8FA60020 27A70020 0411FBEF 00000000 00402021 0411FE52 00000000 13C0000D 02802021 8E650000 00BE2823 8FA2002C 00452821 03C03021 27A70020 0411FBE2 00000000 00402021 0411FE45 00000000 02802021 00002821 00003021 27A70020 0411FBD9 00000000 00402021 0411FE3C 00000000 10000013 8E030000 02802021 8FA5002C 27A70020 0411FBCF 00000000 00402021 0411FE32 00000000 02802021 00002821 00003021 27A70020 0411FBC6 00000000 00402021 0411FE29 00000000 8E030000 24020004 5462000A 8E030000 02802021 02E02821 27A60011 0411FD50 00000000 00402021 0411FE1D 00000000 8E030000 24020005 5462003C 8E030000 265200A0 02802021 02E02821 02403021 0411FDE1 00000000 00402021 0411FE10 00000000 92430008 24020016 5462000A 82420009 02802021 02E02821 02403021 0411FDD5 00000000 00402021 0411FE04 00000000 82420009 50400023 A2200000 92420008 30420010 54400006 2402003C 24130001 02331821 00001021 1000000C 2405000C A2220001 24020044 A2220002 24020069 A2220003 24020072 A2220004 2402003E A2220005 1000FFF2 24130006 02422021 90840009 A0640000 24420001 1445FFFB 24630001 2402000C AFA20020 26440009 0411F7E4 00000000 2673FFFF 02629821 A2330000 8E030000 24020006 5462003E 8E030000 3C029D00 8C420040 0040F809 3404C800 0040B821 02802021 27A50011 0411FCD0 00000000 00402021 0411FDCF 00000000 02802021 00002821 0411F9B0 00000000 00402021 0411FDC8 00000000 02E09021 0000B021 24130001 02802021 02402821 24060080 27A70020 0411FA02 00000000 00402021 0411FDBC 00000000 8FA30020 1860000E 00001021 02421821 80630000 54600006 24420001 52600004 24420001 AFA20020 00009821 24420001 8FA30020 0043202A 5480FFF5 02421821 24020080 14620003 02C3B021 1000FFE3 26520080 02F6B021 A2C00000 A2C00001 3C029D00 8C4200B8 02E02021 0040F809 00002821 8E030000 24020007 5462004D 8E020000 02802021 27A50011 0411FC95 00000000 00402021 0411FD94 00000000 02802021 00002821 0411F975 00000000 00402021 0411FD8D 00000000 3C129D00 8E420040 0040F809 24040100 00409821 8E5600C0 24120001 3C179D00 1000001D 241E000D 1452FFFF 02602021 8EE200C8 0040F809 02C02821 0040B021 02602021 0411F77C 00000000 02621821 A07E0000 2404000A A0640001 02802021 02602821 24460002 27A70020 0411FB0A 00000000 00402021 0411FD6D 00000000 82C20000 14400005 00000000 82C20001 50400005 A2600000 82C20000 1440FFE2 00000000 A2600000 A2600001 02802021 02602821 24060002 27A70020 0411FAF6 00000000 00402021 0411FD59 00000000 02802021 00002821 00003021 27A70020 0411FAED 00000000 00402021 0411FD50 00000000 8E020000 1440002D 3C029D00 8C420090 92230000 12A00006 A0430030 3C029D00 8C420090 8EA30000 10000005 A043003C 3C029D00 8C420090 24030002 A043003C 3C029D00 8C430090 80640030 8C420088 00041880 00621021 8C430000 24020065 1062000B 3C109D00 8E020010 24050008 0040F809 00003021 8E030090 8E020010 80640030 24050065 0040F809 00003021 3C109D00 8E030090 8E02001C 80640030 0040F809 2405FFFD 8E030090 8E02001C 80640030 0040F809 24050006 8FBF0054 8FBE0050 8FB7004C 8FB60048 8FB50044 8FB40040 8FB3003C 8FB20038 8FB10034 8FB00030 03E00008 27BD0058 '.rodata 'err0 6E6B6E55 206E776F 6F727265 000A0D72 'err1 6B736944 72724520 0A0D726F 00000000 'err2 20746F4E 64616552 000A0D79 'err3 46206F4E 0D656C69 0000000A 20746F4E 6E65704F 0A0D6465 00000000 20746F4E 62616E45 0D64656C 0000000A 46206F4E 20656C69 74737953 0A0D6D65 00000000 20746F4E 6E756F6D 0D646574 0000000A End CSub |
||||
| robertquaas Newbie  Joined: 08/05/2016 Location: Hong KongPosts: 3 |
Can you post a link or attache the tiger.ppm image please ? I would like to try it. Thanks
RQ |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10570 |
It is too big to post. Just right click the image above and save it. Then use any photo program to convert it to a binary .PPM |
||||
| robertquaas Newbie Joined: 08/05/2016 Location: Hong KongPosts: 3 |
I am using coreldraw X10 and it doesn't have the PPM option to save it., possible to email me ? robertquaas@163.com Thanks RQ |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10570 |
Robert has just discovered that some graphics programs do not add a comment in the .PPM header which my program assumed. The attached DisplayPicture routine fixes this. Please substitute this update in the above program '***************************************************************************************************
' ' Display a picture from the SD card on SSD1963 ' Picture must be in binary .PPM format ' ' Parameters are: ' PIC$ = filename of the picture to be displayed ' StartX% = X coordinate of the top left of the picture ' StartY% = Y coordinate of the top left of the picture ' ' Note: the routine checks that the picture is not too big for the screen and reports an error if it is ' Sub DisplayPicture(PIC$, StartX%, StartY%) LOCAL Buffer$,addbuffer$ length 3 LOCAL Result%=-1 LOCAL NumBytes%,a%,i% local integer buff(511) SDcard fileopen,PIC$ 'Read the first 128 bytes Buffer$=STRING$(128," ") SDcard readfile,buffer$,0,len(buffer$),NumBytes% a%=instr(buffer$,chr$(10)) ' look for the first CR if left$(buffer$,a%-1)="P6" then buffer$=right$(buffer$,len(buffer$)-a%) if left$(buffer$,1)="#" then a%=instr(buffer$,chr$(10)) ' look for the second CR buffer$=right$(buffer$,len(buffer$)-a%) endif a%=instr(buffer$,chr$(32)) ' look for the space between dimensions local width%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the third CR LOCAL height%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the fourth CR buffer$=right$(buffer$,len(buffer$)-a%) a%=len(buffer$) mod 3 addBuffer$=STRING$(3-a%," ") ' we need to make sure we have a number of bytes divisible by three in the buffer SDcard readfile,addbuffer$,-1,len(addbuffer$),NumBytes% buffer$=buffer$+addbuffer$ if (StartX%+width%>MM.HRES) OR (StartY%+height%>MM.VRES) then print pic$," too big", width%," x",height% else defineregionSSD StartX%, StartY%, width%, height% DisplayBufferSSD Buffer$ do SDcard readfile,buff(),-1,4095,NumBytes% if numbytes%<>0 then DisplayBufferSSD Buff(),numbytes% loop while NumBytes%<>0 endif else Print "Invalid File Format" endif end sub |
||||
| robertquaas Newbie Joined: 08/05/2016 Location: Hong KongPosts: 3 |
Hi Peter Thanks for the update. Now I have downloaded the BMP to PPM Converter from: http://www.contenta-converter.com All images converted from [BMP (800x480), 7" Touchscreen running 100pin Micromite] to PPM and clear and clean. The Contenta converter is trialware for 30 days for those who have interest in this thread. All the best and thanks again. Robert Q |
||||
lew247 Guru Joined: 23/12/2015 Location: United KingdomPosts: 1702 |
Thanks Peter, the work you do is truly amazing |
||||
| Phil23 Guru Joined: 27/03/2016 Location: AustraliaPosts: 1667 |
Try XnView as a simple Photo assistant tool. When you add it's shell extension, XnShell, it has a lot of common tasks in it's right-click context menu. Not a replacement for PS or Corel, but very useful & quick to use tools. It has PPM; don't know about the header, just a check box labelled ascii in the PPM options. Phil. |
||||
| lew247 Guru Joined: 23/12/2015 Location: United KingdomPosts: 1702 |
Peter This line [quote]const SD_CS_PIN = 47 'Connection to CS on SD card[/quote] Does this pin HAVE to be 47 or can it be 52? The reason I ask is I've been using your "Big Ben" code and it's connected to pin 52 on the pcb I've been using and it works fine, just about to test this but not sure if I'll have to mod the pcb or not |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10570 |
Whatever suits your board is fine |
||||
| lew247 Guru Joined: 23/12/2015 Location: United KingdomPosts: 1702 |
I'm getting this error [quote][13] SDcard fileopen,PIC$ Error: Pin 9 is invalid [/quote] I've only got 1 .ppm picture on the SD card so I've ommited the scanning routing [code]const SD_CS_PIN = 52 'Connection to CS on SD card CLS RGB(blue) sdcard mount,SD_CS_PIN,0 'set up the chip select pin for the SDcard and SPI speed to maximum DisplayPicture "image.ppm",0,0 END Sub DisplayPicture(PIC$, StartX%, StartY%) LOCAL Buffer$,addbuffer$ length 3 LOCAL Result%=-1 LOCAL NumBytes%,a%,i% local integer buff(511) SDcard fileopen,PIC$ 'Read the first 128 bytes Buffer$=STRING$(128," ") SDcard readfile,buffer$,0,len(buffer$),NumBytes% a%=instr(buffer$,chr$(10)) ' look for the first CR if left$(buffer$,a%-1)="P6" then buffer$=right$(buffer$,len(buffer$)-a%) if left$(buffer$,1)="#" then a%=instr(buffer$,chr$(10)) ' look for the second CR buffer$=right$(buffer$,len(buffer$)-a%) endif a%=instr(buffer$,chr$(32)) ' look for the space between dimensions local width%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the third CR LOCAL height%=val(left$(buffer$,a%-1)) buffer$=right$(buffer$,len(buffer$)-a%) a%=instr(buffer$,chr$(10)) ' look for the fourth CR buffer$=right$(buffer$,len(buffer$)-a%) a%=len(buffer$) mod 3 addBuffer$=STRING$(3-a%," ") ' we need to make sure we have a number of bytes divisible by three in the buffer SDcard readfile,addbuffer$,-1,len(addbuffer$),NumBytes% buffer$=buffer$+addbuffer$ if (StartX%+width%>MM.HRES) OR (StartY%+height%>MM.VRES) then print pic$," too big", width%," x",height% else defineregionSSD StartX%, StartY%, width%, height% DisplayBufferSSD Buffer$ do SDcard readfile,buff(),-1,4095,NumBytes% if numbytes%<>0 then DisplayBufferSSD Buff(),numbytes% loop while NumBytes%<>0 endif else Print "Invalid File Format" endif end sub[/code] EDIT: If I change SDcard fileopen,PIC$ to SDcard fileopen I just get a black screen |
||||
| lew247 Guru Joined: 23/12/2015 Location: United KingdomPosts: 1702 |
Ignore the previous, got it doing what I need it to do thanks |
||||
| TrevorH Senior Member  Joined: 06/04/2018 Location: United KingdomPosts: 145 |
@matherp I have been looking at this topic , an old thread I know but do you have the source code available, as I would like to cobble together a version to work with my CPLD display. I assume the version in the thread is purely for the SSD1963. Is there any advantage in using PetitFat over the standard SD routines in the MM+ E100? Trevor. |
||||
| matherp Guru Joined: 11/12/2012 Location: United KingdomPosts: 10570 |
The MM+ used to use the Microchip SD card routines which were slow. Recent releases have migrated to FatFS so this thread is now redundant. The only way to go faster is this thread which you already know about and includes source |
||||
