'GPIO USED: GP2 Fire, GP3 Left,GP4 Right
Const JF=4 'GP2
Const JL=5 'GP3
Const JR=6 'GP4

SetPin JF, DIN, pulldown:'fire
SetPin JL, DIN, pulldown:'left
SetPin JR, DIN, pulldown:'right

Do While Inkey$<>" "
Print @(74,210) "  PRESS FIRE TO START   "
for btn=1 to 60
 If Pin(jf) Then Exit sub
 Pause 10
next btn
Print @(82,210) "                    "
for btn=1 to 60
 If Pin(jf) Then Exit sub
 Pause 10
next btn
Loop

'-----------------Init----------------
'
'GPIO USED: GP2 Fire, GP3 Left,GP4 Right
'Change this for your Input Ports
'
Const JF=4 'GP2
Const JL=5 'GP3
Const JR=6 'GP4
'
'-------------------------------------

'PIONES - PIO SPI for NES controller

'PIONES is software that runs on the RP2040 PIO state machines to read from
'NES controllers (SPI). This is indenpendent of the 2 ARM cores.
'For VGA picomite PIO 0 is used to generate VGA. PIO 1 is used for PIONES

'-------------------------------- IO pin configuration -------------------------
'VGApicomiteGAME board revision 1.4

'pin asignment   Port A/K8/sm0       Port B/K7/sm1
'data (in)         gp1                  gp4
'latch (out)       gp2                  gp5
'clk (out)         gp3                  gp22


'--------------------------------- PIO configuration --------------------------
'note: the PIO program for both PIO statemachines is the same, the IO definition
'in the pinctrl register is different. The statemachines actually run same code

'PIO1 execute frequency (identical for all state machines)
f=100000

'PIO1 shift register control (identical for all state machines)
s=2^19                            'set bit 19 = IN shift left, OUT shift right

'PIO1 sm0 config
'When your NES controller is connected to different pins, adapt below 4 lines.
SetPin gp1,pio1 'data
SetPin gp2,pio1 'latch
SetPin gp3,pio1 'clock
p0=Pio(pinctrl 1,1,1,gp1,gp3,gp2,gp3)   'GP1=IN base GP2=SET GP3=OUT/SIDESET
'                     ^   ^   ^   ^
'                     |   |   |   +---- clock pin
'                     |   |   +-------- latch pin
'                     |   +------------ clock pin (second definition of same pin)
'                     +---------------- data pin

'PIO1 sm1 config
'When your 2nd NES controller connects to different pins, adapt below 4 lines.
SetPin gp4,pio1 'data
SetPin gp5,pio1 'latch
SetPin gp22,pio1 'clock
p1=Pio(pinctrl 1,1,1,gp4,gp22,gp5,gp22) 'GP4=IN base, GP5=SET GP22=OUT/SIDESET
'                     ^   ^   ^   ^
'                     |   |   |   +---- clock pin
'                     |   |   +-------- latch pin
'                     |   +------------ clock pin (second definition of same pin)
'                     +---------------- data pin


'------------------------------ PIO program (comment) -------------------------
'pio1 sm0 program, identical code for sm0 and sm1, clock is side set pin
'adr/instr/comment
'0 E081 'set pindir latch, out     [side 0]
'1 E000 'set latch low             [side 0]
'2 A0EB 'MOV null inverted to OSR  [side 0] OSR = &hffffffff
'3 6081 'OUT 1 bit OSR to pindirs  [side 0] set clock to output (pindir = 1)

'4 E001 'latch high                [side 0] latch pulse
'5 E000 'latch low                 [side 0]
'6 E027 'load X with value 7       [side 0] counter for bits shifted in
'7 A0C3 'mov NULL to ISR           [side 0] clear shift register

'8 4001 'shift 1 bit data in ISR   [side 0] adress 8 and 9 are the shift in loop
'9 1048 'JMP X-- to &h8            [side 1] this is the clock pulse
'A 8000 'push ISR                  [side 0] 8 bits to fifo
'B 0004 'jmp to &h4                [side 0] next cycle

'&h0C....&h1F not used
'------------------------- END PIO program (comment) --------------------------


'-------------------------------- START PIO 1 ---------------------------------

'PIO1 program (hex data values are from above listing)
Dim a%(7)=(&h6081A0EBE000E081,&hA0C3E027E000E001,&h0004800010484001,0,0,0,0,0)

'program and start the PIO1 state machines
PIO program 1,a%()                    'program PIO1
PIO init machine 1,0,f,p0,,s,0        'init sm0 from address &h00
PIO init machine 1,1,f,p1,,s,0        'init sm1 from address &h00 (run same code)
PIO start 1,0                         'start PIO1 sm0
PIO start 1,1                         'start PIO1 sm1

Print "PIO 1 running"



'------------------------------ MAIN level test code -----------------------------
dim h%(4)   'read PIO fifo's to this array

'power the 2 ports K8 and K7 only if needed by hardware platform
SetPin gp14,dout:Pin(gp14)=1
SetPin gp15,dout:Pin(gp15)=1


'read the FIFO's that contain the NES controller keys
'  the FIFO's are 4 levels deep, are autonomously filled from the statemachines
'  when full, new data is refused. To get the latest NES controller status, read 4
'  old fifo values, the 5'th values is just entered in the fifo, and is actual.

Do
 PIO read 1,0,5,h%()    'read 5 values (h%(0...4)) from FIFO sm0
 Print Hex$(255-h%(4)), 'print actual (h%(4)) value inverted (switches pull down)
 PIO read 1,1,5,h%()    'read 5 values (h%(0...4)) from FIFO sm1
 Print Hex$(255-h%(4))  'print actual (h%(4)) value inverted (switches pull down)
 Pause 100
Loop While Inkey$=""

End

'adaptation for piones handler
do
 'Do While Inkey$<>" "
 Print @(74,210) "  PRESS FIRE TO START   "
 for i=1 to 60
   Pause 10
   pio read 1,0,5,NES%()
   if 255-NES%(4)=&h80 then exit do
 next i
 Print @(82,210) "                    "
 for i=1 to 60
   Pause 10
   pio read 1,0,5,NES%()
   if 255-NES%(4)=&h80 then exit do
 next i
loop
'end of adaptation for piones handler
End Sub
