Forum Index : Microcontroller and PC projects : AS3935 lightning detector

     Page 1 of 4
Author Message
TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 10:28pm 24 Jun 2017
Copy link to clipboard
Print this post

I have been porting Arduino code for the AS3935 lightning detector and have run into a problem.

MMbasic expects the I2C address to be between 8 and 127 to be considered valid.

The AS3935 chip has 2 address lines to set the I2C address but they only give us zero to three as possible addresses.
My module came fixed with 3 as the address.

Arduino doesn't seem to worry about the 0 to 7 addresses and lets them through but MMbasic throws an error (as it should).

I think I can use the I2CPort CFUNCTION on the MX chip-sets as it appears to be more forgiving. I need to setup and do a real life test to be sure.

Unfortunately, the MMX can't use CFUNCTIONS and that was the platform I used for developing.

I can change to one of the MX chips but is it feasible to relax the address checking for 7 bit addresses?

I will also investigate using SPI instead but I like to leave that for the display.

Jim


VK7JH
MMedit

Geoffg

Guru

Joined: 06/06/2011
Location: Australia
Posts: 3292
Posted: 11:19pm 24 Jun 2017
Copy link to clipboard
Print this post

  TassyJim said  is it feasible to relax the address checking for 7 bit addresses?

That is a good point. If real world devices use these addresses then why disallow them?

GeoffEdited by Geoffg 2017-06-26
Geoff Graham - http://geoffg.net

BobD

Guru

Joined: 07/12/2011
Location: Australia
Posts: 935
Posted: 11:22pm 24 Jun 2017
Copy link to clipboard
Print this post

See the attachment about I2C addressing.
It looks like it is possible but using a reserved address.
2017-06-25_092139_I2C_Slave_Addressing.pdf

matherp
Guru

Joined: 11/12/2012
Location: United Kingdom
Posts: 10315
Posted: 11:35pm 24 Jun 2017
Copy link to clipboard
Print this post

Jim

Completely untested - test for 0-7 removed

100/144 pin

2017-06-25_093449_Micromite.X.production.zip

Let me know and I'll do a proper release


TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 11:52pm 24 Jun 2017
Copy link to clipboard
Print this post

Thanks Peter,
I will give it a try but it will not be until tomorrow now.

I think the chip manufacturer of the chip was too stingy to apply for an I2C address range they could use and didn't want to cause problems by using someone elses.

It certainly had me guessing for a while!

Jim

VK7JH
MMedit

bigmik

Guru

Joined: 20/06/2011
Location: Australia
Posts: 2950
Posted: 02:32pm 25 Jun 2017
Copy link to clipboard
Print this post

Hi Jim,

The chip can also respond using SPI by pulling (I think it was from memory) Pin 9 low...

Regards,

Mick
Mick's uMite Stuff can be found >>> HERE (Kindly hosted by Dontronics) <<<

TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 08:59pm 25 Jun 2017
Copy link to clipboard
Print this post

Yes Mick,
SPI is the next challenge.

I have it working on I2C on the MMX with a modified version of MMBasic from Peter.

All I need now is an electrical storm to see if it really works.

I will post the code once I have SPI working.

Jim
VK7JH
MMedit

CaptainBoing

Guru

Joined: 07/09/2016
Location: United Kingdom
Posts: 2170
Posted: 01:28am 26 Jun 2017
Copy link to clipboard
Print this post

  TassyJim said
All I need now is an electrical storm to see if it really works.



be careful what you wish for

I use this quite a bit - but thankfully we aren't battered so much as you guys
https://www.lightningmaps.org/?lang=en#m=sat;r=0;t=3;s=0;o=0;b=;n=0;y=53.9845;x=-6.1304;z=7;d=2;dl=2;dc=0;

you might be able to use it for your testing (you could even contribute once it is all working)Edited by CaptainBoing 2017-06-27

Phil23
Guru

Joined: 27/03/2016
Location: Australia
Posts: 1667
Posted: 12:03pm 26 Jun 2017
Copy link to clipboard
Print this post

  CaptainBoing said  I use this quite a bit - but thankfully we aren't battered so much as you guys
https://www.lightningmaps.org/?lang=en#m=sat;r=0;t=3;s=0;o=0;b=;n=0;y=53.9845;x=-6.1304;z=7;d=2;dl=2;dc=0;

you might be able to use it for your testing (you could even contribute once it is all working)


I use it too.

But contributing is not that easy, you need to apply to purchase one of their units.
You go on a list & they then assess your location & adjust your position in the list.

As stocks of the kit become available, you will be offered on if you have a low ranking on their list.

I applied back in March I think, & was ranked dead bottom initially, around the 1700's mark.

Checked again some weeks later & my ranking had dropped a bit (Smaller Better), but checked again a few moments ago & I'm now 2176/2176.

So either dropped off the list completely, or NSW/Australia is not considered of interest to the developers.

Their production run of boards seems to be in the 50/100 mark every few months or more.

That got me interested in these other modules.

Cheers

Phil.

Justplayin

Guru

Joined: 31/01/2014
Location: United States
Posts: 328
Posted: 01:12pm 26 Jun 2017
Copy link to clipboard
Print this post

  bigmik said  The chip can also respond using SPI by pulling (I think it was from memory) Pin 9 low...


I've been working on a SPI version with less than stellar results. It's difficult to test a lightening detector when there is no real lightening to detect. I invested in a lightening "emulator" shield and an Arduino Uno which helped produced some encouraging results with my MMBasic code. However; when a real lightening storm came through recently, all I detected was three "disturbers". A disturber is a detection which is considered to be man made noise. So... It's back to the drawing board.

--Curtis
I am not a Mad Scientist...  It makes me happy inventing new ways to take over the world!!

TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 02:10pm 26 Jun 2017
Copy link to clipboard
Print this post

  Justplayin said
I've been working on a SPI version with less than stellar results.
--Curtis

Is your unit indoors or outdoor?

I can get the disturber response easily enough too.

I will start with an outdoor location and play with the noise floor levels.
At least getting a few disturber triggers lets you know that it is alive.

I still think that having a dog frantically trying to climb up my leg is a more reliable detector.

Jim
VK7JH
MMedit

Justplayin

Guru

Joined: 31/01/2014
Location: United States
Posts: 328
Posted: 02:54pm 26 Jun 2017
Copy link to clipboard
Print this post

  TassyJim said
  Justplayin said
I've been working on a SPI version with less than stellar results.
--Curtis

Is your unit indoors or outdoor?

I can get the disturber response easily enough too.

I will start with an outdoor location and play with the noise floor levels.
At least getting a few disturber triggers lets you know that it is alive.


I configured it for "indoors". For my initial setup and testing I used a piezoelectric camp stove igniter to trigger disturbers on-demand. When I test with the lightening emulator, I get varying distance and power readings as expected.

I'll be playing with the indoor outdoor setting and sensitivity setting. Also, the board manufacturer provided a calibration value for the internal tuning capacitors. I have been using that value for the TRCO recalibration. I think I'll try to have the software determine the value on startup like the Arduino code does.

  TassyJim said  I still think that having a dog frantically trying to climb up my leg is a more reliable detector.


Yep... The dog is a very reliable lightening detector.

If Dog = Under.Bed Then Print "Lightening detected!!"



--Curtis

I am not a Mad Scientist...  It makes me happy inventing new ways to take over the world!!

TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 04:53pm 26 Jun 2017
Copy link to clipboard
Print this post

Curtis,
I am having problems getting the SPI to talk.
Can you post your SPI settings or a snippet of code showing a read or write to the chip?

SPI is not familiar territory for me.

Jim
VK7JH
MMedit

Justplayin

Guru

Joined: 31/01/2014
Location: United States
Posts: 328
Posted: 07:00pm 26 Jun 2017
Copy link to clipboard
Print this post

Here is a quick brute force clip which will read the main settings registers from the chip. I actually did my testing by reading the data table (0x09 to 0x32) so I could compare the values and verify I was actually reading the registers correctly.

Geoff provides two ways to read and write SPI, I find this method work best for me.


DIM AA(10) AS Integer
'**** SPI Port Setting ****
Spi Open 1000000, 1, 8
' pin 3 is SPI Out for MicroMite 170
' pin 25 is SPI Clock for MicroMite 170
' Pin 14 is SPI In for MicroMite 170
LightCS = 26 'Chip Select for Lightening Detector board
Setpin LightCS, Dout
Pin(LightCS) = 1 'Deselect Ligtening Detector CS with high
PAUSE 50

Pin(LightCS) = 0 'select Ligtening Detector
PAUSE 50
SPI WRITE 1, 64 'Read starting at register 0
SPI READ 9, AA() 'Read 8 bytes (registers 0 to 8)
Print AA(0), AA(1), AA(2), AA(3), AA(4), AA(5), AA(6), AA(7), AA(8)
Pin(LightCS) = 1 'Deselect Ligtening Detector



* unfortunately I'm unable to test this clip on the hardware I have on hand, but it should work as I copied it from my test program and added a few comments.

--Curtis
I am not a Mad Scientist...  It makes me happy inventing new ways to take over the world!!

CaptainBoing

Guru

Joined: 07/09/2016
Location: United Kingdom
Posts: 2170
Posted: 07:29pm 26 Jun 2017
Copy link to clipboard
Print this post

  TassyJim said
I still think that having a dog frantically trying to climb up my leg is a more reliable detector.


poor pup I had a greyhound bitch years ago (she was a real sweetie and smart too) but we knew there was a storm coming long before we could hear it. She just dissolved into a trembling, panting mess, clearly terrified.

(just had her dew-claws removed and feeling very sorry for herself)


TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 09:27pm 26 Jun 2017
Copy link to clipboard
Print this post

All working on SPI now Curtis.
I had the SPI setting correct but had the 'read/write' bit wrong. Serves me right for coding with a bad head cold.

This code is set for SPI but has the I2C code there as well.
change I2Cmode = 1 and you are in I2C land but it will not work on the current micromites because of the 'illegal' device address used.

There are functions to do most things and a small main program to setup and listen.

' lightning detector code translated from Arduino code
' by Jim Hiley tassyjim on TBS forum
'
'* SEN-39001-R01 (universal applications)
'* ---> http://www.playingwithfusion.com/productview.php?pdid=22
'*
'* Copyright © 2015 Playing With Fusion, Inc.
'* SOFTWARE LICENSE AGREEMENT: This code is released under the MIT License.
'*
'* Permission is hereby granted, free of charge, to any person obtaining a
'* copy of this software and associated documentation files (the "Software"),
'* to deal in the Software without restriction, including without limitation
'* the rights to use, copy, modify, merge, publish, distribute, sublicense,
'* and/or sell copies of the Software, and to permit persons to whom the
'* Software is furnished to do so, subject to the following conditions:
'*
'* The above copyright notice and this permission notice shall be included in
'* all copies or substantial portions of the Software.
'*
'* THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
'* IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
'* FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
'* AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
'* LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING
'* FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER
'* DEALINGS IN THE SOFTWARE.
'* **************************************************************************
'* REVISION HISTORY:
'* Author Date Comments
'* J. Steinlage 2015Jul20 I2C release based on SPI example
'*
'* Playing With Fusion, Inc. invests time and resources developing open-source
'* code. Please support Playing With Fusion and continued open-source
'* development by buying products from Playing With Fusion!
'*
'* **************************************************************************
'* APPLICATION SPECIFIC NOTES (READ THIS!!!):
'* - This file configures then runs a program on a micromite to interface with
'* an AS3935 Franklin Lightning Sensor manufactured by AMS.
'* - Perform setup for AS3935 chip
'* --- capacitance registers for tuning (based on cal value provided)
'* --- configurations for your application specifics (indoor/outdoor, etc)
'* - read status/info from sensor
'* - Write formatted information to serial port
'* - Set configs for your specific needs using the #defines for wiring, and
'* review the setup() function for other settings (indoor/outdoor, for example)
'* - I2C specific note: This example uses the I2C interface via the I2C lib, not
'* the 'Wire' lib included with the Arduino IDE.
'*
'* Circuit:
' I2C SPI --> SEN-39001: AS3935 Breakout
'* SDA MOSI --> MOSI/SDA
' nc MISO --> MISO
'* SCK SCK --> SCK/SCL
'* 3.3V GND --> SI select interface; GND=SPI, VDD=I2C
'* IRQ_PIN IRQ_PIN --> IRQ use a count pin for reading freq when calibrating
'* GND CS_PIN --> CS pull CS to ground for I2C
'* GND GND --> GND
'* 3.3V 3.3V --> Micromite I/O is at 3.3V, so power board from 3.3V
'**************************************************************************/
OPTION EXPLICIT
'option default none
DIM AS INTEGER I2Cmode = 0 ' 1 = I2C 0 = SPI
' defines for hardware config
DIM AS INTEGER CS_PIN = 4 ' CS used for SPI mode, GND for I2C
DIM AS INTEGER IRQ_PIN = 6 ' any suitable pin for interrupt
DIM AS INTEGER AS3935_ADD = &H03 ' x03 - standard PWF SEN-39001-R01 config
DIM AS INTEGER AS3935_CAPACITANCE = 96 ' <-- SET THIS VALUE TO THE NUMBER LISTED ON YOUR BOARD
SETPIN CS_PIN, DOUT
PIN(CS_PIN) = 1-I2Cmode

' defines for general chip settings
'dim as integer AS3935_INDOORS = 0
DIM AS INTEGER AS3935_OUTDOORS = 0 ' 1 = outdoors 0 = indoor
'dim as integer AS3935_DIST_DIS = 0
DIM AS INTEGER AS3935_DIST_EN = 1
DIM AS INTEGER re, AS3935_ISR_Trig, int_src, lightning_dist_km

AS3935_setup
SETPIN IRQ_PIN, INTH, AS3935_ISR
'
DO
' This program only handles an AS3935 lightning sensor. It does nothing until
' an interrupt is detected on the IRQ pin.
IF AS3935_ISR_Trig = 1 THEN ' lightning sensor triggered
PAUSE 5
' reset interrupt flag
AS3935_ISR_Trig = 0
' now get interrupt source
int_src = AS3935_GetInterruptSrc()
SELECT CASE int_src
CASE 0
PRINT "interrupt source result not expected"
CASE 1
lightning_dist_km = AS3935_GetLightningDistKm();
PRINT "Lightning detected! Distance to strike: ";
PRINT lightning_dist_km;
PRINT " kilometers"
CASE 2
PRINT "Disturber detected"
CASE 3
PRINT "Noise level too high"
CASE ELSE
PRINT "OOPS!! The module shouldn't return "+STR$(int_src)
END SELECT
re = AS3935_PrintAllRegs() ' for debug...
ENDIF
LOOP

END

SUB AS3935_setup
PRINT "Playing With Fusion: AS3935 Lightning Sensor, SEN-39001-R01"
PRINT "beginning boot procedure...."
re = AS3935_DefInit() ' set registers to default
' now update sensor cal for your application and power up chip
re = AS3935_ManualCal(AS3935_CAPACITANCE, AS3935_OUTDOORS, AS3935_DIST_EN)
' AS3935_ManualCal Parameters:
' --> capacitance, in pF (marked on package)
' --> indoors/outdoors (AS3935_INDOORS:0 / AS3935_OUTDOORS:1)
' --> disturbers (AS3935_DIST_EN:1 / AS3935_DIST_DIS:2)
' function also powers up the chip
re = AS3935_PrintAllRegs()
AS3935_ISR_Trig = 0 ' clear trigger
END SUB


SUB AS3935_ISR
' this is irq handler for AS3935 interrupts,
' always make code in interrupt handlers fast and short
AS3935_ISR_Trig = 1
END SUB

FUNCTION AS3935_reg_read(RegAdd)
LOCAL RegData
IF I2Cmode = 1 THEN
I2C OPEN 400, 1000
I2C WRITE AS3935_ADD, 1, 1, RegAdd
PAUSE 1
I2C READ AS3935_ADD, 1, 1, RegData
I2C CLOSE
ELSE
SPI OPEN 1000000, 1, 8
PIN(CS_PIN) = 0
PAUSE 1
RegData = SPI((RegAdd AND &H3F) OR &H40)
RegData = SPI(&H00)
PIN(CS_PIN) = 1
SPI CLOSE
ENDIF
AS3935_reg_read = RegData
END FUNCTION

FUNCTION AS3935_reg_write(RegAdd, DataMask, RegData)
LOCAL OrigRegData, NewRegData, re
' start by reading original register data (only modifying what we need to)
OrigRegData = AS3935_reg_read(RegAdd)
' calculate new register data... 'delete' old targeted data, replace with new data
' note: 'DataMask' must be bits targeted for replacement
' add'l note: this function does NOT shift values into the proper place... they need to be there already
NewRegData = ((OrigRegData AND (&HFF XOR DataMask)) OR (RegData AND DataMask))
' finally, write the data to the register
IF I2Cmode = 1 THEN
I2C OPEN 400, 1000
PAUSE 1
I2C WRITE AS3935_ADD, 1, 2, RegAdd, NewRegData
AS3935_reg_write = MM.I2C
I2C CLOSE
ELSE
SPI OPEN 1000000, 1, 8
PIN(CS_PIN) = 0
PAUSE 1
SPI WRITE 2, (RegAdd AND &H3F),NewRegData
PIN(CS_PIN) = 1
SPI CLOSE
ENDIF
PRINT "wrt: ";HEX$(NewRegData,2);" Act: ";HEX$(AS3935_reg_read(RegAdd),2)' for debugging
END FUNCTION

FUNCTION AS3935_DefInit()
LOCAL re
' run PRESET_DEFAULT Direct Command to set all registers in default state
IF I2Cmode = 1 THEN
I2C OPEN 400, 1000
PAUSE 1
I2C WRITE AS3935_ADD, 1, 2, &H3C, &H96
AS3935_DefInit = MM.I2C
I2C CLOSE
ELSE
SPI OPEN 1000000, 1, 8
PIN(CS_PIN) = 0
PAUSE 1
SPI WRITE 2, &H3C,&H96
PIN(CS_PIN) = 1
SPI CLOSE
ENDIF
PAUSE 2 ' wait 2ms to complete
END FUNCTION

FUNCTION CalRCO()
' run ALIB_RCO Direct Command to cal internal RCO
IF I2Cmode = 1 THEN
I2C OPEN 400, 1000
PAUSE 1
I2C WRITE AS3935_ADD, 1, 2, &H3D, &H96
CalRCO = MM.I2C
I2C CLOSE
ELSE
SPI OPEN 1000000, 1, 8
PIN(CS_PIN) = 0
PAUSE 1
SPI WRITE 2, &H3D,&H96
PIN(CS_PIN) = 1
SPI CLOSE
ENDIF
PAUSE 2 ' wait 2ms to complete
END FUNCTION

FUNCTION AS3935_PowerUp()
LOCAL re
' power-up sequence based on datasheet, pg 23/27
' register 0x00, PWD bit: 0 (clears PWD)
re = AS3935_reg_write(&H00, &H01, &H00)
re = CalRCO() ' run RCO cal cmd
re = AS3935_reg_write(&H08, &H20, &H20) ' set DISP_SRCO to 1
PAUSE 2
re = AS3935_reg_write(&H08, &H20, &H00) ' set DISP_SRCO to 0
AS3935_PowerUp = 1
END FUNCTION

FUNCTION AS3935_PowerDown()
LOCAL re
' register 0x00, PWD bit: 0 (sets PWD)
re = AS3935_reg_write(&H00, &H01, &H01)
PRINT "AS3935 powered down"
AS3935_PowerDown = re
END FUNCTION

FUNCTION AS3935_DisturberEn()
LOCAL re
' register 0x03, PWD bit: 5 (resets MASK_DIST)
re = AS3935_reg_write(&H03, &H20, &H00)
PRINT "disturber detection enabled"
AS3935_DisturberEn = re
END FUNCTION

FUNCTION AS3935_DisturberDis()
LOCAL re
' register 0x03, PWD bit: 5 (sets MASK_DIST)
re = AS3935_reg_write(&H03, &H20, &H20)
PRINT "disturber detection disabled"
AS3935_DisturberDis = re
END FUNCTION

FUNCTION AS3935_SetIRQ_Output_Source(irq_select)
LOCAL re
' set interrupt source - what to displlay on IRQ pin
' reg 0x08, bits 5 (TRCO), 6 (SRCO), 7 (LCO)
' only one should be set at once, I think
' 0 = NONE, 1 = TRCO, 2 = SRCO, 3 = LCO
SELECT CASE irq_select
CASE 1
re = AS3935_reg_write(&H08, &HE0, &H20) ' set only TRCO bit
CASE 2
re = AS3935_reg_write(&H08, &HE0, &H40) ' set only SRCO bit
CASE 3
re =AS3935_reg_write(&H08, &HE0, &H80) ' set only LCO bit
CASE ELSE ' assume 0
re =AS3935_reg_write(&H08, &HE0, &H00) ' clear IRQ pin display bits
END SELECT
AS3935_SetIRQ_Output_Source = re
END FUNCTION

FUNCTION AS3935_SetTuningCaps(cap_val)
LOCAL re
' Assume only numbers divisible by 8 (because that's all the chip supports)
IF cap_val >= 120 THEN ' cap_value out of range, assume highest capacitance
re =AS3935_reg_write(&H08, &H0F, &H0F) ' set capacitance bits to maximum
ELSE
re =AS3935_reg_write(&H08, &H0F, (cap_val>>3)) ' set capacitance bits
ENDIF
re = AS3935_reg_read(&H08) AND &H0F
PRINT "capacitance set to 8x";STR$(re);" = ";STR$(re * 8);"pF"
AS3935_SetTuningCaps = re
END FUNCTION

FUNCTION AS3935_GetInterruptSrc()
LOCAL re, int_src
' definition of interrupt data on table 18 of datasheet
' for this function:
' 0 = unknown src, 1 = lightning detected, 2 = disturber, 3 = Noise level too high
PAUSE 3 ' wait 3ms before reading (min 2ms per pg 22 of datasheet)
int_src = (AS3935_reg_read(&H03) AND &H0F) ' read register, get rid of non-interrupt data
SELECT CASE int_src
CASE &H08
re = 1 ' lightning caused interrupt
CASE &H04
re = 2 ' disturber detected
CASE &H01
re = 3 ' Noise level too high
CASE ELSE
re = 0 ' interrupt cause unknown
END SELECT
AS3935_GetInterruptSrc = re
END FUNCTION

FUNCTION AS3935_GetLightningDistKm()
LOCAL strike_dist
strike_dist = (AS3935_reg_read(&H07) AND &H3F) ' read register, get rid of non-distance data
AS3935_GetLightningDistKm = strike_dist ' 63 equals out of range
END FUNCTION

FUNCTION AS3935_GetStrikeEnergyRaw()
LOCAL energy_raw
energy_raw = (AS3935_reg_read(&H06) AND &H1F) << 8 ' MMSB, shift 8 bits left, make room for MSB
energy_raw = energy_raw OR AS3935_reg_read(&H05) ' read MSB
energy_raw = energy_raw << 8 ' shift 8 bits left, make room for LSB
energy_raw = energy_raw OR AS3935_reg_read(&H04) ' read LSB, add to others
AS3935_GetStrikeEnergyRaw = energy_raw
END FUNCTION

FUNCTION AS3935_SetMinStrikes(min_strk)
LOCAL re
' This function sets min strikes to the closest available number, rounding to the floor,
' where necessary, then returns the physical value that was set. Options are 1, 5, 9 or 16 strikes.
' see pg 22 of the datasheet for more info (#strikes in 17 min)
SELECT CASE min_strk
CASE 1
re = AS3935_reg_write(&H02, &H30, &H00)
re = 1
CASE min_strk < 9
re = AS3935_reg_write(&H02, &H30, &H10)
re = 5
CASE min_strk < 16
re = AS3935_reg_write(&H02, &H30, &H20)
re = 9
CASE ELSE
re = AS3935_reg_write(&H02, &H30, &H30)
re = 16
END SELECT
AS3935_SetMinStrikes = re
END FUNCTION

FUNCTION AS3935_SetIndoors()
' AFE settings addres 0x00, bits 5:1 (10010, based on datasheet, pg 19, table 15)
' this is the default setting at power-up (AS3935 datasheet, table 9)
AS3935_SetIndoors = AS3935_reg_write(&H00, &H3E, &H24)
PRINT "set up for indoor operation"
END FUNCTION

FUNCTION AS3935_SetOutdoors()
' AFE settings addres 0x00, bits 5:1 (01110, based on datasheet, pg 19, table 15)
AS3935_SetOutdoors = AS3935_reg_write(&H00, &H3E, &H1C)
PRINT "set up for outdoor operation"
END FUNCTION

FUNCTION AS3935_ClearStatistics()
LOCAL re
' clear is accomplished by toggling CL_STAT bit 'high-low-high' (then set low to move on)
re = AS3935_reg_write(&H02, &H40, &H40) ' high
re = AS3935_reg_write(&H02, &H40, &H00) ' low
re = AS3935_reg_write(&H02, &H40, &H40) ' high
AS3935_ClearStatistics = 1
END FUNCTION

FUNCTION AS3935_GetNoiseFloorLvl()
LOCAL reg_raw
' NF settings addres 0x01, bits 6:4
' default setting of 010 at startup (datasheet, table 9)
reg_raw = AS3935_reg_read(&H01) ' read register 0x01
AS3935_GetNoiseFloorLvl = (reg_raw AND &H70)>>4 ' should return value from 0-7, see table 16 for info
END FUNCTION

FUNCTION AS3935_SetNoiseFloorLvl(nf_sel)
' NF settings addres 0x01, bits 6:4
' default setting of 010 at startup (datasheet, table 9)
IF nf_sel <= 7 THEN ' nf_sel within expected range
AS3935_SetNoiseFloorLvl = AS3935_reg_write(&H01, &H70, ((nf_sel AND &H07)<<4))
ELSE ' out of range, set to default (power-up value 010)
AS3935_SetNoiseFloorLvl = AS3935_reg_write(&H01, &H70, &H20)
ENDIF
END FUNCTION

FUNCTION AS3935_GetWatchdogThreshold()
LOCAL reg_raw
' This function is used to read WDTH. It is used to increase robustness to disturbers,
' though will make detection less efficient (see page 19, Fig 20 of datasheet)
' WDTH register: add 0x01, bits 3:0
' default value of 0001
' values should only be between 0x00 and 0x0F (0 and 7)
reg_raw = AS3935_reg_read(&H01)
AS3935_GetWatchdogThreshold = reg_raw AND &H0F
END FUNCTION

FUNCTION AS3935_SetWatchdogThreshold(wdth)
' This function is used to modify WDTH. It is used to increase robustness to disturbers,
' though will make detection less efficient (see page 19, Fig 20 of datasheet)
' WDTH register: add 0x01, bits 3:0
' default value of 0001
' values should only be between 0x00 and 0x0F (0 and 7)
AS3935_SetWatchdogThreshold = AS3935_reg_write(&H01, &H0F, (wdth AND &H0F))
END FUNCTION

FUNCTION AS3935_GetSpikeRejection()
LOCAL reg_raw
' This function is used to read SREJ (spike rejection). Similar to the Watchdog threshold,
' it is used to make the system more robust to disturbers, though will make general detection
' less efficient (see page 20-21, especially Fig 21 of datasheet)
' SREJ register: add 0x02, bits 3:0
' default value of 0010
' values should only be between 0x00 and 0x0F (0 and 7)
reg_raw = AS3935_reg_read(&H02)
AS3935_GetSpikeRejection = reg_raw AND &H0F
END FUNCTION


FUNCTION AS3935_SetSpikeRejection(srej)
' This function is used to modify SREJ (spike rejection). Similar to the Watchdog threshold,
' it is used to make the system more robust to disturbers, though will make general detection
' less efficient (see page 20-21, especially Fig 21 of datasheet)
' WDTH register: add 0x02, bits 3:0
' default value of 0010
' values should only be between 0x00 and 0x0F (0 and 7)
AS3935_SetSpikeRejection = AS3935_reg_write(&H02, &H0F, (srej & &H0F))
END FUNCTION

FUNCTION AS3935_SetLCO_FDIV(fdiv)
' This function sets LCO_FDIV register. This is useful in the tuning of the antenna
' LCO_FDIV register: add 0x03, bits 7:6
' default value: 00
' set 0, 1, 2 or 3 for ratios of 16, 32, 64 and 128, respectively.
' See pg 23, Table 20 for more info.
AS3935_SetLCO_FDIV = AS3935_reg_write(&H03, &HC0, ((fdiv AND &H03) << 5))
END FUNCTION

FUNCTION AS3935_PrintAllRegs()
'local energy_val
PRINT ""
PRINT TIME$;" ";DATE$
PRINT "Reg &H00: ";HEX$(AS3935_reg_read(&H00),2)
PRINT "Reg &H01: ";HEX$(AS3935_reg_read(&H01),2)
PRINT "Reg &H02: ";HEX$(AS3935_reg_read(&H02),2)
PRINT "Reg &H03: ";HEX$(AS3935_reg_read(&H03),2)
PRINT "Reg &H04: ";HEX$(AS3935_reg_read(&H04),2)
PRINT "Reg &H05: ";HEX$(AS3935_reg_read(&H05),2)
PRINT "Reg &H06: ";HEX$(AS3935_reg_read(&H06),2)
PRINT "Reg &H07: ";HEX$(AS3935_reg_read(&H07),2)
PRINT "Reg &H08: ";HEX$(AS3935_reg_read(&H08),2)
'
PRINT "AFE Gain Boost: ";BIN$((AS3935_reg_read(&H00)AND &B00111110)>>1,5)
PRINT "Power-down: ";BIN$((AS3935_reg_read(&H00)AND &B00000001),1)
PRINT "Noise Floor Level: ";BIN$((AS3935_reg_read(&H01)AND &B01110000)>>4,3)
PRINT "Watchdog threshold: ";BIN$((AS3935_reg_read(&H01)AND &B00001111),4)
PRINT "Clear statistics: ";BIN$((AS3935_reg_read(&H02)AND &B01000000)>>6,1)
PRINT "Minimum num lightning:";BIN$((AS3935_reg_read(&H02)AND &B00110000)>>4,2)
PRINT "Spike rejection: ";BIN$((AS3935_reg_read(&H02)AND &B00001111),4)
PRINT "Freq div -ant tuning: ";BIN$((AS3935_reg_read(&H03)AND &B11000000)>>6,2)
PRINT "Mask Disturber: ";BIN$((AS3935_reg_read(&H03)AND &B00100000)>>5,1)
PRINT "Interrupt: ";BIN$((AS3935_reg_read(&H03)AND &B00001111),4)
PRINT "Energy LSB: ";BIN$(AS3935_reg_read(&H04)AND &B11111111,8)
PRINT "Energy MSB: ";BIN$(AS3935_reg_read(&H05)AND &B11111111,8)
PRINT "Energy MMSB: ";BIN$(AS3935_reg_read(&H06)AND &B00011111,5)
PRINT "Distance estimation: ";BIN$(AS3935_reg_read(&H07)AND &B00111111,6)
PRINT "Display LCO on IRQ: ";BIN$((AS3935_reg_read(&H08)AND &B10000000)>>7,1)
PRINT "Display SRCO on IRQ: ";BIN$((AS3935_reg_read(&H08)AND &B01000000)>>6,1)
PRINT "Display TRCO on IRQ: ";BIN$((AS3935_reg_read(&H08)AND &B00100000)>>5,1)
PRINT "Internal Tuning Caps: ";BIN$(AS3935_reg_read(&H08)AND &B00001111,4)
PRINT "Energy: ";STR$(AS3935_GetStrikeEnergyRaw())
END FUNCTION

FUNCTION AS3935_ManualCal(capacitance, location, disturber)
LOCAL re
' start by powering up
re = AS3935_PowerUp()
' indoors/outdoors next...
IF location = 1 THEN ' set outdoors if 1
re = AS3935_SetOutdoors()
ELSE ' set indoors if anything but 1
re = AS3935_SetIndoors()
ENDIF
' disturber cal
IF disturber = 0 THEN ' disabled if 0
re = AS3935_DisturberDis()
ELSE ' enabled if anything but 0
re = AS3935_DisturberEn()
ENDIF
re = AS3935_SetIRQ_Output_Source(0)

PAUSE 500
' capacitance first... directly write value here
re = AS3935_SetTuningCaps(capacitance)
PRINT "AS3935 manual cal complete"
END FUNCTION



When an event is detected, it prints a dump of the registers
Disturber detected

17:02:34 27-06-2017
Reg &H00: 24
Reg &H01: 22
Reg &H02: C2
Reg &H03: 00
Reg &H04: 35
Reg &H05: FC
Reg &H06: 07
Reg &H07: 3F
Reg &H08: 0C
AFE Gain Boost: 10010
Power-down: 0
Noise Floor Level: 010
Watchdog threshold: 0010
Clear statistics: 1
Minimum num lightning:00
Spike rejection: 0010
Freq div -ant tuning: 00
Mask Disturber: 0
Interrupt: 0000
Energy LSB: 00110101
Energy MSB: 11111100
Energy MMSB: 00111
Distance estimation: 111111
Display LCO on IRQ: 0
Display SRCO on IRQ: 0
Display TRCO on IRQ: 0
Internal Tuning Caps: 1100
Energy: 523317


I haven't played around with calibrating yet.
Maybe tomorrow.


VK7JH
MMedit

CircuitGizmos

Guru

Joined: 08/09/2011
Location: United States
Posts: 1427
Posted: 04:41am 27 Jun 2017
Copy link to clipboard
Print this post

  TassyJim said
I still think that having a dog frantically trying to climb up my leg is a more reliable detector.

Jim


Impossible to find in SMT.
Micromites and Maximites! - Beginning Maximite

Phil23
Guru

Joined: 27/03/2016
Location: Australia
Posts: 1667
Posted: 11:31am 27 Jun 2017
Copy link to clipboard
Print this post

Looking good,

Can't wait to give it a try.
Am I right in thinking I can't use it in SPI mode on an LCD Backpack if I also need the SPI bus for the display?

Or will both co-exist with the CS overriding the display as required.

Have you worked out what the individual module calibration is about yet?
I've only read of it on their website & can't say I noticed it in the Arduino code.

[Quote]We store calibration values for each board shipped. This information can be provided at your request by contacting Technical Support and referencing your original order number.[/quote]

Phil.

TassyJim

Guru

Joined: 07/08/2011
Location: Australia
Posts: 6283
Posted: 01:03pm 27 Jun 2017
Copy link to clipboard
Print this post

Phil,
My unit came with the calibration value printed on the package - 96pF
Once I have it in a suitable case, I will re-calibrate.

The unit is a receiver centered on 500kHz. In calibration mode, the tuned circuit frequency is output on the INT pin so it can easily be measured.
Simply read the frequency and keep changing the capacitance value register until the frequency is close to 500kHz.
The functions to do this are in my code.
All I need to do is to put together a main program to use the functions. Maybe today sometime.
The micromite should be OK to use for the measurement provided the CLOCKTRIM has been set.

Using multiple devices on the same SPI bus should be OK provided the CS pin is used on ALL devices. Once the lightning detector is running, any communications with it are not time critical so fitting reads between display activity should be easy enough.

Jim

VK7JH
MMedit

Justplayin

Guru

Joined: 31/01/2014
Location: United States
Posts: 328
Posted: 03:30pm 27 Jun 2017
Copy link to clipboard
Print this post

Looks great Jim! Doesn't work for me, but it looks great!

Right now I am getting a constant scrolling screen with "Noise level too high". I think the problem is the WDTH value. The docs say the default should be 1, but as read from the register on startup it's 2. In my own code, I set it to 1 which nearly eliminated all the noise level messages.

I don't have any time tonight to play around with your code... maybe tomorrow (darn job!) .

--Curtis
I am not a Mad Scientist...  It makes me happy inventing new ways to take over the world!!

     Page 1 of 4
Print this page
The Back Shed's forum code is written, and hosted, in Australia.
© JAQ Software 2025
